SPECIFICATION

SPECIFICATION

Category

PET & Can Combined Automated Return Machine

Can Automated Return Machine

Transparent PET Automated Return Machine

Item Identification Number

24148236
24954210
25794481

Dimensions(mm)

660(W) X 740(D) X 1,670(H)
660(W) X 740(D) X 1,670(H)
660(W) X 740(D) X 1,690(H)

Material

STS 201

STS 304

STS 201

STS 304

STS 201

STS 304

Weighing Unit Capacity

MAX 100kg

MIN 50g

MAX 100kg

MIN 50g

MAX 100kg

MIN 50g

Load Cell

MAX 100kg/2point
MAX 100kg/2point
MAX 100kg/2point

Power Supply Voltage


DC 12V / 5A
DC 12V / 5A
DC 12V / 5A

Power Consumption

32W
32W
32W
DATA Transmission
LTE
LTE
LTE

Payment Methods

Prepaid/Postpaid

Prepaid/Postpaid/Credit Card

Prepaid/Postpaid/Credit Card

Excellent Procurement

Scheduled for 2026

・Communication: LTE ・Finish: Powder coating / Silk screen printing / Wrapping ・Power: AC220

HT-200BS [Prepaid / Postpaid]

Category

Dimensions(mm)660(W)×700(D)×1,650(H)
Material
FULL Stainless Steel
Weighing Capacity
MAX 150kg/50g
Load Cell
MAX 150kg, 2Point
Power Supply VoltageDC 12V / 5A
Power Consumption
85W
Weight
81kg
RFID Reader
13.56Mhz, ISO14443, ISO 15693
Data Transmission
LTE
Collection capacity
120L

SPECIAL

SPECIAL

Application of touch panel for the first time in the volume-based machine

LED Touch Panel
  • Excellent visibility
    Numeric display size increased to twice that of conventional models, with bright and clear LED illumination.

  • Reliable operation with a single touch
    Highly responsive panel that ensures accurate recognition even with a light touch.

  • Outstanding durability
    Acrylic material reduces failure rate compared to conventional PE panels.

  • User-friendly design
    Control panel conveniently located at the upper right for easy operation.

Easy Maintenance

Full collection bin indicator

  • Regular and on-demand equipment monitoring

  • Real-time fault detection and fault history management

Administrator SMS notification service
  • Regular and on-demand equipment monitoring

  • Real-time fault detection and fault history management

User convenience

Voice guidance
  • Automatic volume adjustment according to time and location

  • User-adjustable volume with 10 levels

Disposal using a password (PIN)
  • When the card is not available, disposal can be done using a password

  • Postpaid billing only

Easy Cleaning

Easy cleaning with a detachable inlet
  • Inlet designed with a detachable structure

  • Can be removed separately for cleaning

Prevents rainwater from entering the collection bin
  • Blocks rainwater intrusion into the bin

  • Rainwater protection enables proper bin capacity management and maintains weighing accuracy

Integrated Management System (A/S)

Real-time monitoring
  • Monitoring equipment at regular intervals
  • Real-time fault identification, fault history management
 National A/S Center
  • Establishment of A/S infrastructure nationwide including Je
  • Run a dedicated call center to respond quickly
